01
Audit and consulting
We assess the facility, check existing installations and recommend solutions for identified deficiencies.
View detailsProtecție SRL · Your engineering partner
Design, Installation & Maintenance of Sprinkler Fire Protection Systems
We design, install and maintain fire protection, water supply and pumping systems. One partner, from the first sketch through to operation.
Solutions for commercial, residential and industrial buildings
Since 1993
Engineering experience
300+
Completed projects
Full lifecycle
From design to maintenance
30+
International manufacturers
Our services
One partner.
From audit to maintenance.
02
Design
We design fire protection, water supply, pumping and building engineering solutions.
View details
03
Equipment supply
We select and supply equipment to suit the design, facility parameters and client requirements.
View details
04
Fire protection system installation
We install fire suppression, detection, alarm and evacuation warning systems, as well as smoke control automation.
View details
05
Pumping equipment installation
We install fire pumping, pressure boosting and water supply stations, including automation.
View details
06
Low-current system installation
We integrate video surveillance, security alarms, access control and communication networks.
View details
07
Commissioning and testing
We configure equipment, carry out tests and verify the operation of installed systems.
View details
08
Technical maintenance
We provide scheduled inspections, diagnostics, repairs and upgrades for existing systems.
View details01 / The sprinkler system
Components of a sprinkler system
Main technical components
Water supply source
- Fire water storage tank and/or connection to the public water supply;
- Above-ground or underground tank, as specified in the design;
- Fire brigade connection for supplementary water supply.
Pump set
- Main fire pump – electrically driven;
- Standby pump – electric or diesel-driven, where specified;
- Jockey pump – maintains system pressure and compensates for minor leaks;
- Suction and discharge manifolds;
- Isolation valves and check valves;
- Pressure gauges and pressure switches;
- Electrical control and automation panels.
Sprinkler control valve assembly
- Control and alarm assembly / alarm valve;
- Main control valve;
- Alarm valve;
- Check valve;
- Pressure gauges;
- Alarm pressure switch;
- Test device;
- Drain pipe and drain valve;
- Where required, a retard chamber and water motor alarm gong for alarm signalling.
Pipework network
- Main supply pipe;
- Vertical risers;
- Distribution mains;
- Branch lines;
- Fittings: elbows, tees, reducers, couplings and more;
- Supports, brackets and fixings;
- Expansion joints and flexible connections where required;
- Section isolation valves.
Sprinklers
- Pendent sprinklers;
- Upright sprinklers;
- Sidewall sprinklers;
- Standard-response or quick-response sprinklers;
- Different activation temperatures, for example 57°C, 68°C, 79°C, 93°C and others;
- Different K-factors, selected according to the hydraulic calculation and the hazard being protected.
A standard sprinkler is individually sealed by a heat-sensitive element. At the rated temperature, the element breaks or releases, allowing water to discharge.
Normally, not all sprinklers activate simultaneously, only those heated sufficiently by the fire.
Monitoring and alarm equipment
- Flow switch / water flow detector;
- Pressure switches;
- Valve position supervisory switches;
- Tank level sensors;
- Pump set sensors and pressure switches;
- Signals such as “Fire Pump Running”, “Fault” and “Low Pressure”;
- Signal transmission to the fire alarm control panel or BMS, as specified in the design.
Testing and maintenance equipment
- Inspector’s Test Connection;
- Test and drain valves;
- Drain pipes;
- Pressure measurement points;
- Flow meter or pump test circuit, depending on the configuration.
Simplified diagram
- Water tank
- Fire pump set
- Manifold
- Control / alarm assembly
- Risers
- Distribution pipes
- Branch lines
- Sprinklers
International equipment. Integrated solutions.
02 / One partner
From a plan.
To a working system.
We coordinate every stage. You work with a team that knows the facility and takes responsibility for continuity throughout the project.
Assess and design
We assess the facility, clarify requirements and develop the technical solution.
Supply and install
We select equipment and install the systems.
Test and commission
We configure automation and verify system operation.
Maintain and upgrade
Scheduled inspections, diagnostics, repairs and upgrades.
03 / Experience in practice
Solutions for real facilities.
Centru logistic Nord
Equipment: Sprinklere; hidranți interiori; stație de pompare
Services: Audit; proiectare; furnizare; montaj; punere în funcțiune
Discuss a similar projectEvery project begins with a discussion.
Tell us about your object. We’ll determine the next step together.
